AIRETOS Wi-Fi7 Products: faster, deterministic, aware
Wi-Fi 7 (IEEE 802.11be) is the first Wi-Fi generation engineered for systems that cannot afford to wait. Multi-Link Operation (MLO) lets a device hold simultaneous links across 2.4, 5, and 6 GHz and move traffic between them without renegotiating; 320 MHz channels and 4K QAM raise the throughput ceiling into multi-gigabit territory; and the same radio that carries the data can now sense, locate, and range.
AIRETOS brings Wi-Fi 7 to both ends of the link: the AIRETOS C27 Class puts industrial-grade Wi-Fi 7 + Bluetooth 6.0 into the device — robots, drones, gateways, edge AI — while the AIRETOS E92 Class builds the infrastructure those devices connect to, on Qualcomm's Dragonwing™ NPro 7 access-point silicon. One vendor, one engineering culture, both sides of the deployment.
E92 Class
WiFi7 DBS Infrastructure
Wi-Fi 7 module family in 4×4 single-radio or 2×2 + 2×2 dual-radio configurations, powered by the Qualcomm® QCN9274 / QCN6274 Dragonwing™ NPro 7 Platform and built on VOXMICRO's patent-pending WAVIA™ architecture. Single-band, dual-band diplexed, dual-independent-radio, and 4×4 single-radio modes on the same module foundation. Infrastructure-grade, module-down LGA for thin, dense, integrated systems — with slotted M.2 and mPCIe on the same architecture. Up to 11.5 Gbps peak dual-radio PHY, 320 MHz in 6 GHz, up to 256 clients per radio.
Module-down solution – based on Waikiki reference design.
C27 Class
WiFi7 DBS multimodal & dual-BT6
Industrial multimodal Wi-Fi 7 + Bluetooth 6.0 LGA module on the Qualcomm® FastConnect™ C7700. Tri-band 2×2 with up to 5.8 Gbps silicon peak PHY (MLO, 320 MHz, 4K QAM), always-on Wi-Fi Aux Radio, Wi-Fi Location (802.11az) + Wi-Fi Sensing (CSI), and Bluetooth 6.0 2×2 with BLE Long Range and silicon-level Channel Sounding. PCIe Gen 3 today — USB 3.0 and SDIO 3.0 variants in development — on one industrial-grade LGA platform, −40 °C to +85 °C.
Engineered for Physical AI – Based on QCC2072/0 - FastConnect C7700 - Cologne reference design.
MRSP Starting at $34.95
One Wi-Fi 7 portfolio. Both ends of the link.
Most module vendors sell you one side of a Wi-Fi 7 deployment. AIRETOS covers the link end-to-end — the client radio inside your product and the infrastructure radio it talks to.
Designing both sides together pays off where it matters most: MLO-aware roaming, deterministic latency budgets, and one accountable engineering partner from the device to the access point.
Compliance
Wi-Fi 7 raises the regulatory bar again: tri-band operation across 2.4, 5, and 6 GHz, per-domain 6 GHz rules that are still evolving country by country, and power classes (from low-power indoor upward) that shape what a product may do in each market. Modular approval strategy now decides certification cost and time-to-market more than ever. AIRETOS Wi-Fi 7 modules are engineered for modular approval across the major regulatory domains, and custom host-system antennas can be qualified for additional modular approval on request.
Double the highway, denser traffic on it.
Wi-Fi 7 doubles the maximum channel width to 320 MHz in the 6 GHz band and moves peak modulation from 1024-QAM to 4096-QAM (4K QAM) — around 20 % more bits per symbol on top of the doubled bandwidth. In AIRETOS terms: up to 5.8 Gbps silicon peak PHY on the C27 client side, and up to 11.5 Gbps peak dual-radio PHY on E92 infrastructure.
One device, several links, zero renegotiation.
An MLO device maintains simultaneous links across 2.4, 5, and 6 GHz and steers traffic between them per-packet. If one band is jammed, congested, or being scanned, traffic keeps flowing on the others. For mobile platforms — AGVs, AMRs, drones — MLO architecturally enables lower-disruption roaming by pre-establishing on a secondary link before transitioning the primary.
Engineered for control loops, not just downloads.
MLO redundancy, preamble puncturing and Multi-RU operation (using a partially occupied channel instead of abandoning it), and refined QoS and Target Wake Time scheduling shrink both latency and — more importantly for industrial systems — latency variance. That is the difference between "fast Wi-Fi" and wireless you can put inside a machine-control or safety-adjacent loop.
Connectivity that senses, locates, and ranges.
The Wi-Fi 7 generation pairs data transport with spatial awareness: Wi-Fi Location (IEEE 802.11az) for precision ranging, Channel State Information (CSI) capture for presence and motion sensing, and — on the Bluetooth 6.0 side — Channel Sounding for sub-meter ranging between devices. On the AIRETOS C27, the same module that carries the network senses the space around it: no additional hardware in the BOM.
Channel Sounding is a Bluetooth 6.0 silicon-platform capability; AIRETOS C27 module-level firmware exposure publishes with general availability. Centimetric Wi-Fi ranging requires pairing with capable infrastructure.
